Blue dark grey 0.38mm - 3.04mm PVB film AGC clear laminated safety glass for long corridor

Blue dark grey 0.38mm - 3.04mm PVB film AGC clear laminated safety glass for long corridor

Blue dark grey 0.38mm - 3.04mm PVB film AGC clear laminated safety glass for long corridor

Product Details:

Place of Origin: China
Brand Name: Northglass
Certification: ASTM C1048,BS6206,ANSI Z97-1,GB9963
Model Number: CE, ASTM, CSI, etc
Contact Now
Detailed Product Description

Blue, dark grey 0.38mm - 3.04mm PVB film AGC clear laminated safety glass for long corridor

AGClaminated glass/Sandwich glass/Interlayer glass is processed with special technology under high temperature and high pressure by adding one or more layers of Polyvinyl Butyral (PVB) with tough and strong binding between or among two or more glass layers(AGCglass is one of these glass). For the great binding performance, AGClaminated glass/sandwich glass/interlayer glass could stop external force attack and the chips will bind with PVB after breakage to avoid making harm to person. And AGClaminated glass/sandwich glass/interlayer glass could still resist attack from wind and rain in breakage status.

In order to guarantee the quality of AGC laminated glass/sandwich glass/interlayer glass, PVB film could be imported from Du Pont of USA or Sekisui of Japan to make AGC laminated glass/sandwich glass/interlayer glass. We also have Chinese famous brand PVB for laminated glass with high quality and transparency. AGC laminated glass/sandwich glass/interlayer glasscan be further processed into tempered laminated glass, glass with holes, into insulating glass etc.



Applications:



AGC laminated glass/sandwich glass/interlayer glass is widely used for bullet proof, burglar-proof, showcase, counter, aquarium, skylight, long corridor, sidelite, etc, especially in cold or hot areas.





Specifications:

AGC laminated glass/Sandwich glass/Interlayer glass size:

Max. Size:2440mm*6000mm
Min. Size:300mm*300mm
Thickness of PVB film:0.38mm-3.04mm

Low Elaminated glass/Sandwich glass/Interlayer glassthickness(mm): 4+0.38+4, 5+0.38+5, 4+0.76+4, 5+0.76+5, etc

The colors of PVB film include transparent, milk, blue, dark grey, light green, bronze, etc.

Standard: EN 12543; ANSI Z 97.1 200; BS 6206



Competitive Advantage:



AGC laminated glass/sandwich glass/interlayer glass advantages:

Sound reduction, the special laminated construction could reduce sound spread effectively, then that function make laminated glass has great performance in sound control, PVB also could filter and absorb ultraviolet (UV) rays 99.5% at least, so laminated glass could reduce the cost of electronic power and save energy, the effects will be better if you adopt special PVB interlayer.



Features of AGCLow E laminated glass/sandwich glass/interlayer glassas following:

1)Extremely high safety: The PVB interlayer withstands penetration from impact. Even if the glass cracks, splinters will adhere to the interlayer and not scatter. In comparison with other kinds of glass, AGClaminated glass has much higher strength to resist shock, burglary, burst and bullets.

2) Energy-saving building materials: PVB interlayer impedes the transmission of solar heat and reduces cooling loads.

3) Create aesthetic sense to buildings: AGC Laminated glass with a tinted interlayer will beautify the buildings and harmonize their appearances with surrounding views which meet the demand of architects.

4) Sound control: PVB interlayer is an effective absorber of sound.

5) Ultraviolet screening: The interlayer filters out ultraviolet rays and prevents the furniture and curtains from fading effect



Quality Standards

GB 15763.2, Chinese standard.

EN 12150.1, European standard.

EN 12600,  European standard.
