Place of Origin: | China |
Brand Name: | Hehe |
Certification: | SPF,3C,TUV,ISO9001 |
Model Number: | 3.2mm,4.0mm |
Solar energy materials: | pv products |
---|
Minimum Order Quantity: | 1000 Sqm |
---|---|
Price: | $4.85/sqm |
Packaging Details: | Pallet,Crat. |
Delivery Time: | within 10 days after confirmed |
Payment Terms: | T/T,L/C at sight. |
Supply Ability: | 500,000SQM. |
1 Specification
Thickness: 3.2mm/4mm
Max size: 2300mm*1500mm
Edge: Straight Edge
Corner: Cut
Type: single coating, Double coating
Surface patterns: one side Patterned
2 Performance Data Sheet
Inspection Item |
Test Method |
StandardValue |
Unit |
Detection Data |
Light Transmittance |
(D65) (within the spectral range of wave length between 380nm-1100nm) |
>93.5 |
% |
94.11 |
Pencil Hardness |
GB/T 6739 |
≥4 |
H |
5 |
Brushing Resistance Test |
After 400times of brushing tests, measure the attenuation value of light transmittance |
≤1.0 |
% |
0.4 |
Water Resistance |
After 96 hours water resistance test, measure the attenuation value of light transmittance |
≤0.5 |
% |
0.1 |
Acid Resistance Test |
Steep the sample in the hydrochloric acid of 1mol/L under the temperature of 23℃±0.2 ℃ for 24 hours, measure the attenuation value of light transmittance. |
≤1.0 |
% |
0.3 |
Salt Spray Test |
NaCl solution of 5% ±1%,spray under 35℃ for 96 hours, measure the attenuation value of light transmittance |
≤1.0 |
% |
0.15 |
Temperature Resistance Test |
Repeat 200 times (about 1000hours) under the temperature from -40℃ to 85℃±0.2 ℃, measure the attenuation value of light transmittance |
≤1.0 |
% |
0.63 |
Humid Heat Test |
Temperature 85±0.2℃,relative humidity 85% ±5%, test time 1000 hours, measure the attenuation value of light transmittance |
≤1.0 |
% |
0.52 |
Wet AND Freeze Test |
Relative humidity 85% ±5%,reduce the temperature from 85℃±0.2 ℃ to -40 ℃ for 10 times, measure the attenuation value of light transmittance |
≤1.2 |
% |
1.05 |
Sand and Dust Test |
Under 23 ℃, maintain the humidity lower than 30%,adjust wind speed at 8.9 ±1.2m/s, blowing dust concentration 10.6± 7g/m3 for 6 hours; adjust wind speed at 1.5± 1m/s,raise temperature to 60℃ for 16 hours; adjust wind speed at 8.9± 1.2m/s, blowing dust concentration 10.6 ± 7g/m3 for 6 hours, then measure the attenuation value of light transmittance |
≤1.0 |
% |
0.88 |
3 Thermal Properties
Heat transfer Coefficient |
5.8 W/m2K |
Expansion Coefficient between 20-300℃ |
per℃=9.03×10-6 m/K |
Specific heat capacity |
0.2 J/Kg·K |
Calculated Thermal Conductivity at 20℃ In |
1.0 W/mK |
Softening Point |
~720℃ |
Annealing Point |
~550℃ |
Stain Point |
~500℃ |
4 Mechanical Properties
Moh’s Scale(Scratch hardness) |
4~5 |
Knoop Hardness Number (indentation Hardness) indenter load-500 grams |
470 |
Poisson’s Ratio |
0.2 |
Density |
2.5 g/cc |
(Yong’s) Modulus of Elasticity |
73.000N/mm2 |
Tensile Strength |
43 N/mm2 |
Pressure resistance |
700-900N/mm2 |
Mechanical Strength |
90N/Mn2 |
5 Quality Standard List
5.1 Tolerance Range
Iterm |
Index |
Thickness tolerance |
±0.2mm(3.2mm) |
Dimension tolerance |
±1.0mm |
Diagonal difference |
≤2mm (diagonal size< 1000mm), ≤4mm (diagonal size>1000mm) |
Iron content |
<115pm |
Overall Bow/warp |
<0.2% |
Local warp |
<0.3mm within 300mm |
5.2 Reasonable Defects Data
Iterm |
Index |
||||
Unclear Pattern |
Visible |
Not Allowed |
|||
Bubble |
Micro bubbles |
≤3.0/㎡ |
|||
Length(L) ㎜ |
2≤L<5 |
5≤L<10 |
L≥10 |
||
Number Allowed |
6*S |
3*S |
0 |
||
Inclusion |
Length(L)㎜ |
2≤L<3 |
L≥3 |
||
Number Allowed |
4*S |
0 |
|||
Line
|
Visible |
Not Allowed |
|||
Number Allowed |
|||||
Dents |
Visible |
Not Allowed |
|||
Number Allowed |
|||||
Wrinkle |
Visible |
Not Allowed |
|||
Scratch |
Visible |
4pcs(L<5mm,W≤1mm), 2pcs(L<5-10mm,W≤1mm), 1pc (L<10-25mm, W≤1mm) |
|||
Number Allowed |
|||||
Crack |
|
Should Not Visible |
|||
Edge |
Broken Edge, Corner |
≤1pc |
|||
Nick, Flange |
L≤10mm; W≤2mm,thickness≤1mm. |
||||
Note: 1,L means length and W means width. S means the area of glass in Meter. Number Allowed is the product of S and its coefficient. 2,Less than 8 bubbles (smaller than 2mm) within one circle with a diameter of 100mm. 3,Devastating inclusion not allowed. |
|||||
6 Packing
Vertical and Horizontal packing, plywood/wood case, inter paper between glass, adding desiccant.
